Reflective glass beads for road marking with high refractive index 6-7 MOHS hardness and environmental protection

Product Details

Place of Origin: Shandong, China

Brand Name: Zhongren

Certification: CE Certification

Payment & Shipping Terms

Minimum Order Quantity: 1 ton

Price: $380.00/tons 3-9 tons

Packaging Details: 25 Kg/ Bag

Delivery Time: 7-15 work days

Payment Terms: L/C,D/A,T/T

Supply Ability: 1-30T, 15 work days

Get Best Price

Chat Now

Product Details

Product Description

Product Details

Highlight:
                                                                                                                                                                                                                                                                                                                                                                                                                                                                                Chemical Resistant Epoxy Resin Floor Paint, Chemical Resistant  Epoxy Concrete Floor Coating, Epoxy Concrete Floor Coating Odoless


Product Name:	Glass Beads	Usage:	Road Marking,Sidewalk & Tactile Paving Markings
Application Method:	Thermoplastic Road Marking Machine	Density:	2.4-2.6g/cm3
Size Distribution:	Oversize ≤5% Under Size ≤10%	Hardness:	6-7 MOHS ;46HRC
Feature:	Bright Smooth Appearance,color And Diverse	Sample:	500g For Free
MOQ:	1ton	Advantage:	High Refractive Index, High Roundness, And Strong Environmental Protection
Color:	White	Packing:	Customized Packing
Keywords:	BS 6088 A .B Reflective Glass Beads For Road Marking

Product Name:	Glass Beads
Usage:	Road Marking,Sidewalk & Tactile Paving Markings
Application Method:	Thermoplastic Road Marking Machine
Density:	2.4-2.6g/cm3
Size Distribution:	Oversize ≤5% Under Size ≤10%
Hardness:	6-7 MOHS ;46HRC
Feature:	Bright Smooth Appearance,color And Diverse
Sample:	500g For Free
MOQ:	1ton
Advantage:	High Refractive Index, High Roundness, And Strong Environmental Protection
Color:	White
Packing:	Customized Packing
Keywords:	BS 6088 A .B Reflective Glass Beads For Road Marking

Product Description

Glass Beads for Road Marking Nd≥1.5 6-7 MOHS for Expressways

Glass beads are used as high-performance, organic materials applied externally to road markings. The beads reduce surface adsorption of dust from the air due to containing specific coupling agents, which improves cohesion with coatings and prevents tiny beads from sinking into the coating. Their flotation function allows them to remain on the coating surface, providing a large surface area that increases utilization by more than 30%. Reflective glass beads have become an irreplaceable material in road safety products.

$Reflective glass beads for road marking with high refractive index 6-7 MOHS hardness and environmental protection 0$

International Standards Compliance

Chinese Standard: GB / T 24722 - 2009 No.1, 2, 3
Korea Standard: KSL 2521 No.1 and 2
British Standard: BS6088 Class A and B
American Standard: AASHTO M247 type 1 and type 2
European Standard: EN1423 and EN1424
Turkish Standard: TS EN1423
New Zealand Standard: NZS2009: 2002
Taiwan Standard: CNS
Japanese Standard: JIS R3301
Australian Standard: A, B, C, D

Technical Specifications

Project	Quality
Chemical composition%	SiO2 >72% CaO >8% Na2O <14% MgO >2.5% Al2O3 0.5-2.0% Fe2O3 0.15% Others 2.0%
Refractive Index	Nd≥1.5%
Density	2.4-2.6g/cm³
Size distribution	Oversize ≤5% under size ≤10%
Wire diameter	0.03-0.4mm
Durability	3-5%
Hardness	6-7 MOHS; 46HRC
Microhardness	≥650kg/cm³
Circularity	Round rate of ≥85%
Appearance	Colorless, glass transparent without impurities, round and smooth
Application	1. Grinding 2. Road marking paint 3. Sand blasting
Lead Content	No lead content, reaches American 16CFR 1303 Lead content standard
Harmful substances content	Lower than American 16CFR 1500 standard
Flammable fire test	Not easy combustion, reaches American 16CFR 1500.44 standard
Soluble heavy metal content	Metal content of soluble matter ratio solid weight rate no more than ASTM F963 corresponding value

Size Specifications

Type	Mesh	Microns Max (μm)	Microns Min (μm)
30#	20-40	850	425
40#	30-40	600	425
60#	40-60	425	300
80#	60-100	300	150
100#	70-140	212	106
120#	100-140	150	106
150#	100-200	150	75
180#	140-200	106	75
220#	140-270	106	53
280#	200-325	75	45
320#	>325	45	25

$Reflective glass beads for road marking with high refractive index 6-7 MOHS hardness and environmental protection 1$ $Reflective glass beads for road marking with high refractive index 6-7 MOHS hardness and environmental protection 2$ $Reflective glass beads for road marking with high refractive index 6-7 MOHS hardness and environmental protection 3$

Frequently Asked Questions

1. Are you a factory?

Yes, we are a coating & abrasive OEM&ODM factory with 21 years of manufacturing experience.

2. What types of coatings does your company offer?

We offer a wide range of coatings including acrylic, epoxy, polyurethane, and latex paints, suitable for various applications from residential to industrial.

3. What colors are available for your coatings?

We offer a comprehensive color palette with custom color matching services to meet your specific color requirements.

4. How about the price?

We can offer the best wholesale price which depends on the quantity of the order.

5. What's your MOQ (min order quantity), production period and delivery time?

Our MOQ is 25 Kg. We accept mixed orders and the production period and delivery time are 7-15 days.

6. Can the packaging be customized?

We support customized packaging and customized logo.

7. Are your coatings environmentally friendly?

We offer environmentally friendly coatings that comply with industry standards for low VOC (volatile organic compounds) and eco-friendly formulations.
