Home > Products > Road Glass Beads > Global Standard Glass Beads for Road Marking: AASHTO M247 & EN1423 Certified Reflective Spheres with 200-850μm Size Distribution and Environmental Friendly

Global Standard Glass Beads for Road Marking: AASHTO M247 & EN1423 Certified Reflective Spheres with 200-850μm Size Distribution and Environmental Friendly

Product Details

Place of Origin: Shandong, China

Brand Name: Zhongren

Certification: CE ISO

Model Number: ZR

Payment & Shipping Terms

Minimum Order Quantity: 1 Ton

Price: $300/ton 1-100 ton

Packaging Details: 1) 25kg/bag,then 40 bags per ton bag. 2) 1000kg in in one ton bag. 3)25kg/bag,then 40 bags in one pallet

Delivery Time: 7-15 work days

Payment Terms: L/C,T/T

Supply Ability: 1 ton 7 work days

Get Best Price
Chat Now
Product Details
Highlight:

Metallic Clear Epoxy Resin Floor Coating

,

Flat Floor Paint Strong Adhesion

,

Strong Adhesion Epoxy Resin Floor Coating

Product Name:
Road Glass Beads
Raw Material:
Glass Sand, Waste Glass
Usage:
Road Marking Paint/Roadway Safty
Feature:
Bright Smooth Appearance,color And Diverse
Size Distribution:
200-850μm
Application:
Thermoplastic Road Marking Paint
Customization Service:
OEM ODM
MOQ:
1 Ton
Advantage:
Eviromental Friendly
Color:
White
Packing:
Customized Packing
Type:
Premixed And Dough-based
Product Name:
Road Glass Beads
Raw Material:
Glass Sand, Waste Glass
Usage:
Road Marking Paint/Roadway Safty
Feature:
Bright Smooth Appearance,color And Diverse
Size Distribution:
200-850μm
Application:
Thermoplastic Road Marking Paint
Customization Service:
OEM ODM
MOQ:
1 Ton
Advantage:
Eviromental Friendly
Color:
White
Packing:
Customized Packing
Type:
Premixed And Dough-based
Product Description
Global Standard Glass Beads For Road Marking: AASHTO M247 & EN1423 Certified Reflective Spheres For Pavement Marking
Product Overview

Glass beads are high-performance, organic materials used in road marking applications. The specialized coating on these beads reduces surface adsorption of dust from the air, while the specific coupling agent improves cohesion with coatings and prevents tiny glass beads from sinking due to their flotation function. When applied, they float on the surface coating, providing a large reflective surface area that increases utilization by more than 30%. Reflective glass beads have become an irreplaceable material in road safety products.

Global Standard Glass Beads for Road Marking: AASHTO M247 & EN1423 Certified Reflective Spheres with 200-850μm Size Distribution and Environmental Friendly 0
Available Specifications

We provide glass beads with different refractive indices including 1.53, 1.72, and 1.93. We can also manufacture glass beads according to various national standards or custom size distributions provided by customers.

International Standards Available
  • Chinese Standard: GB/T 24722-2009 No.1, 2, 3
  • Korean Standard: KSL 2521 No.1 and 2
  • British Standard: BS6088 Class A and B
  • American Standard: AASHTO M247 type 1 and type 2
  • European Standard: EN1423 and EN1424
  • Turkish Standard: TS EN1423
  • New Zealand Standard: NZS2009:2002
  • Taiwan Standard: CNS
  • Japanese Standard: JIS R3301
  • Australian Standard: A, B, C, D
Size Specifications
Type Mesh Microns Max (μm) Microns Min (μm)
30#20-40850425
40#30-40600425
60#40-60425300
80#60-100300150
100#70-140212106
120#100-140150106
150#100-20015075
180#140-20010675
220#140-27010653
280#200-3257545
320#>3254525
Technical Specifications
Project Quality
Chemical Composition %SiO₂ >72%
CaO >8%
Na₂O <14%
MgO >2.5%
Al₂O₃ 0.5-2.0%
Fe₂O₃ 0.15%
Others 2.0%
Refractive IndexNd≥1.5%
Density2.4-2.6g/cm³
Size DistributionOversize ≤5% under size ≤10%
Wire Diameter0.03-0.4mm
Durability3-5%
Hardness6-7 MOHS; 46HRC
Microhardness≥650kg/cm³
CircularityRound rate of ≥85%
AppearanceColorless, glass transparent without impurities, round and smooth
Application1. Grinding 2. Road marking paint 3. Sand blasting
Lead ContentNo lead content, reaches American 16CFR 1303 Lead content standard
Harmful Substances ContentLower than American 16CFR 1500 standard
Flammable Fire TestNot easy combustion, reaches American 16CFR 1500.44 standard
Soluble Heavy Metal ContentMetal content of soluble matter ratio solid weight rate no more than ASTM F963 corresponding value
Package25kg/bag
Global Standard Glass Beads for Road Marking: AASHTO M247 & EN1423 Certified Reflective Spheres with 200-850μm Size Distribution and Environmental Friendly 1 Global Standard Glass Beads for Road Marking: AASHTO M247 & EN1423 Certified Reflective Spheres with 200-850μm Size Distribution and Environmental Friendly 2 Global Standard Glass Beads for Road Marking: AASHTO M247 & EN1423 Certified Reflective Spheres with 200-850μm Size Distribution and Environmental Friendly 3
Frequently Asked Questions
1. Are you a factory?

Yes, we are a coating & abrasive OEM&ODM factory with 21 years of manufacturing experience.

2. What types of coatings does your company offer?

We offer a wide range of coatings including acrylic, epoxy, polyurethane, and latex paints, suitable for various applications from residential to industrial.

3. What colors are available for your coatings?

We offer a comprehensive color palette with custom color matching services to meet your specific color requirements.

4. How about the price?

We can offer the best wholesale price which depends on the quantity of the order.

5. What's your MOQ (minimum order quantity), production period and delivery time?

Our MOQ is 25 Kg. We accept mixed orders and the production period and delivery time are 7-15 days.

6. Can the packaging be customized?

We support customized packaging and customized logo.

7. Are your coatings environmentally friendly?

We offer environmentally friendly coatings that comply with industry standards for low VOC (volatile organic compounds) and eco-friendly formulations.
