Product Details
Place of Origin: Shandong, China
Brand Name: Zhongren
Certification: CE ISO
Model Number: ZR
Payment & Shipping Terms
Minimum Order Quantity: 1 Ton
Price: $300/ton 1-100 ton
Packaging Details: 1) 25kg/bag,then 40 bags per ton bag. 2) 1000kg in in one ton bag. 3)25kg/bag,then 40 bags in one pallet
Delivery Time: 7-15 work days
Payment Terms: L/C,T/T
Supply Ability: 1 ton 7 work days
Product Name: |
Road Glass Beads |
Raw Material: |
Glass Sand, Waste Glass |
Usage: |
Road Marking Paint/Roadway Safty |
Feature: |
Bright Smooth Appearance,color And Diverse |
Size Distribution: |
200-850μm |
Application: |
Thermoplastic Road Marking Paint |
Customization Service: |
OEM ODM |
MOQ: |
1 Ton |
Advantage: |
Eviromental Friendly |
Color: |
White |
Packing: |
Customized Packing |
Type: |
Premixed And Dough-based |
Product Name: |
Road Glass Beads |
Raw Material: |
Glass Sand, Waste Glass |
Usage: |
Road Marking Paint/Roadway Safty |
Feature: |
Bright Smooth Appearance,color And Diverse |
Size Distribution: |
200-850μm |
Application: |
Thermoplastic Road Marking Paint |
Customization Service: |
OEM ODM |
MOQ: |
1 Ton |
Advantage: |
Eviromental Friendly |
Color: |
White |
Packing: |
Customized Packing |
Type: |
Premixed And Dough-based |
Glass beads are high-performance, organic materials used in road marking applications. The specialized coating on these beads reduces surface adsorption of dust from the air, while the specific coupling agent improves cohesion with coatings and prevents tiny glass beads from sinking due to their flotation function. When applied, they float on the surface coating, providing a large reflective surface area that increases utilization by more than 30%. Reflective glass beads have become an irreplaceable material in road safety products.
We provide glass beads with different refractive indices including 1.53, 1.72, and 1.93. We can also manufacture glass beads according to various national standards or custom size distributions provided by customers.
| Type | Mesh | Microns Max (μm) | Microns Min (μm) |
|---|---|---|---|
| 30# | 20-40 | 850 | 425 |
| 40# | 30-40 | 600 | 425 |
| 60# | 40-60 | 425 | 300 |
| 80# | 60-100 | 300 | 150 |
| 100# | 70-140 | 212 | 106 |
| 120# | 100-140 | 150 | 106 |
| 150# | 100-200 | 150 | 75 |
| 180# | 140-200 | 106 | 75 |
| 220# | 140-270 | 106 | 53 |
| 280# | 200-325 | 75 | 45 |
| 320# | >325 | 45 | 25 |
| Project | Quality |
|---|---|
| Chemical Composition % | SiO₂ >72% |
| CaO >8% | |
| Na₂O <14% | |
| MgO >2.5% | |
| Al₂O₃ 0.5-2.0% | |
| Fe₂O₃ 0.15% | |
| Others 2.0% | |
| Refractive Index | Nd≥1.5% |
| Density | 2.4-2.6g/cm³ |
| Size Distribution | Oversize ≤5% under size ≤10% |
| Wire Diameter | 0.03-0.4mm |
| Durability | 3-5% |
| Hardness | 6-7 MOHS; 46HRC |
| Microhardness | ≥650kg/cm³ |
| Circularity | Round rate of ≥85% |
| Appearance | Colorless, glass transparent without impurities, round and smooth |
| Application | 1. Grinding 2. Road marking paint 3. Sand blasting |
| Lead Content | No lead content, reaches American 16CFR 1303 Lead content standard |
| Harmful Substances Content | Lower than American 16CFR 1500 standard |
| Flammable Fire Test | Not easy combustion, reaches American 16CFR 1500.44 standard |
| Soluble Heavy Metal Content | Metal content of soluble matter ratio solid weight rate no more than ASTM F963 corresponding value |
| Package | 25kg/bag |
Yes, we are a coating & abrasive OEM&ODM factory with 21 years of manufacturing experience.
We offer a wide range of coatings including acrylic, epoxy, polyurethane, and latex paints, suitable for various applications from residential to industrial.
We offer a comprehensive color palette with custom color matching services to meet your specific color requirements.
We can offer the best wholesale price which depends on the quantity of the order.
Our MOQ is 25 Kg. We accept mixed orders and the production period and delivery time are 7-15 days.
We support customized packaging and customized logo.
We offer environmentally friendly coatings that comply with industry standards for low VOC (volatile organic compounds) and eco-friendly formulations.
